Compressor Motor Rotor Testing Machine Support USB Flash Drive Exportation

Rotor testing machine for compressor motor

1. Application industry: compressor motor rotor

2. Introduction

• Test dimension range: 50mm＜ rotor iron core diameter＜200mm ；50mm＜rotor iron core thickness＜400mm.
• Test: broken, thin, fullness, short circuit, comprehensive value.
• The rotor testing machine can be applied to both laboratory and production line.

3. Feature

• Testing machine and test bench are integrated or separated according to the size of rotor.
• Conveniently operate, perfectly for customer.
• Full function: test the rotor porosity, sand hole, and residue caused by manufacturing technology and bad material.
• High efficiency: after fixing, the rotor testing machine complete test and output the result in 5 seconds.
• Automatically judge the rotor quality, record the test data, and display the quantity of conducting bar, broken bar, and thin bar.
• The fixture device is driven by the cylinder. Fixture and the movement of sensor are controlled by cylinder, which improve the stability of the test.
• Help and support: there are instruction and test data waveforms analysis in the software.​

4. Configuration list

5. Rotor testing machine picture
